Pipe Tee are commonly known as the 3 way pipe fittings as they resemble the alphabet ‘T’. They are manufactured to manage the direction and mixture of fluids and are also widely used in piping systems to transport two phase fluid mixtures. Tee pipes are manufactured in two types – Equal Tee and Unequal Tee. An equal tee is when the size of the branch is same as header pipes, while an unequal tee is when the branch size is less than that of header size.
We are a leading stainless steel elbow pipe manufacturers that build carbon steel and stainless steel/alloy steel material elbow bend pipe of long and short radius for oil, gas, chemical, utilities, construction, etc. industries.
Parshva Steel And Alloys is a Manufacturer and Exporter of Carbon Steel, Alloy Steel, Stainless Steel, Duplex, Super Duplex & Higher Nickel Alloys Butt Weld Elbows as per ASTM A 234 WPB , WPBW, WPC, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70, ASTM A403 WP Gr. 304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L, ASTM A420 WPL3 /A420WPL6, ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91, ASTM A 815 UNS NO S31803, S32205, S32750, S32760, ASTM/ASME SB 366 UNS2200 (NICKEL 200), UNS 2201 (NICKEL 201), UNS 4400 (MONEL 400), UNS 8020 (ALLOY 20), UNS 8825 (INCONEL 825), UNS 6600 (INCONEL 600), UNS 6601 (INCONEL 601), UNS 6625 (INCONEL 625), UNS 10276 (HASTELLOY C 276) to Dubai, Sharjah, Abu Dhabi , Oman, Qatar, Saudi Arabia, Kuwait, Iran, Iraq, Malaysia, Indonesia, Norway, Nigeria, Algeria, Egypt, Libya, Brazil, Angola, Guinea, Mozambique, Tanzania, Venezuela, Canada, Ecuador, Ghana, Vietnam, Trinidad And Tobago, Thailand, Korea, Taiwan, Australia, Italy, France, Spain, Russia, Germany, Azerbaijan, Kazakhstan, Turkey, Uzbekistan and other countries.
| Nominal Pipe Size | Long | Long | ||
|---|---|---|---|---|
| D1 | D2 | C | M | |
| ½×½×½ ½×½×⅜ ½×½×¼ |
0.84 0.84 0.84 |
0.84 0.68 0.54 |
1.00 1.00 1.00 |
1.00 1.00 1.00 |
| ¾×¾×¾ ¾×¾×½ ¾×¾×⅜ |
1.05 1.05 1.05 |
1.05 0.84 0.68 |
1.12 1.12 1.12 |
1.12 1.12 1.12 |
| 1×1×1 1×1×¾ 1×1×½ |
1.32 1.32 1.32 |
1.32 1.05 0.84 |
1.50 1.50 1.50 |
1.50 1.50 1.50 |
| 1¼×1¼×1¼ 1¼×1¼×1 1¼×1¼×¾ 1¼×1¼×½ |
1.66 1.66 1.66 1.66 |
1.66 1.32 1.05 0.84 |
1.88 1.88 1.88 1.88 |
1.88 1.88 1.88 1.88 |
| 1½×1½×1½ 1½×1½×1¼ 1½×1½×1 1½×1½×¾ 1½×1½×½ |
1.90 1.90 1.90 1.90 1.90 |
1.90 1.66 1.32 1.05 0.84 |
2.25 2.25 2.25 2.25 2.25 |
2.25 2.25 2.25 2.25 2.25 |
| 2×2×2 2×2×1½ 2×2×1¼ 2×2×1 2×2×¾ |
2.38 2.38 2.38 2.38 2.38 |
2.38 1.90 1.66 1.32 1.05 |
2.50 2.50 2.50 2.50 2.50 |
2.50 2.38 2.25 2.00 1.75 |
| 2½×2½×2½ 2½×2½×2 2½×2½×1½ 2½×2½×1¼ 2½×2½×1 |
2.88 2.88 2.88 2.88 2.88 |
2.88 2.38 1.90 1.66 1.32 |
3.00 3.00 3.00 3.00 3.00 |
3.00 2.75 2.62 2.50 2.25 |
| 3×3×3 3×3×2½ 3×3×2 3×3×1½ 3×3×1¼ |
3.50 3.50 3.50 3.50 3.50 |
3.50 2.88 2.38 1.90 1.66 |
3.50 2.88 2.38 1.90 1.66 |
3.38 3.25 3.00 2.88 2.75 |
| 3½×3½×3½ 3½×3½×3 3½×3½×2½ 3½×3½×2 3½×3½×1½ |
4.00 4.00 4.00 4.00 4.00 |
4.00 3.50 2.88 2.38 1.90 |
3.75 3.75 3.75 3.75 3.75 |
3.75 3.62 3.50 3.25 3.12 |
| 4×4×4 4×4×3½ 4×4×3 4×4×2½ 4×4×2 4×4×1½ |
4.50 4.50 4.50 4.50 4.50 4.50 |
4.50 4.00 3.50 2.88 2.38 1.90 |
4.12 4.12 4.12 4.12 4.12 4.12 |
4.12 4.00 3.88 3.75 3.50 3.38 |
| 5×5×5 5×5×4 5×5×3½ 5×5×3 5×5×2½ 5×5×2 |
5.56 5.56 5.56 5.56 5.56 5.56 |
5.56 4.50 4.00 3.50 2.88 2.38 |
4.88 4.88 4.88 4.88 4.88 4.88 |
4.88 4.62 4.50 4.38 4.25 4.12 |
| 6×6×6 6×6×5 6×6×4 6×6×3½ 6×6×3 6×6×2½ |
6.62 6.62 6.62 6.62 6.62 6.62 |
6.62 5.56 4.50 4.00 3.50 2.88 |
5.62 5.62 5.62 5.62 5.62 5.62 |
5.62 5.38 5.12 5.00 4.88 4.75 |
| 8×8×8 8×8×6 8×8×5 8×8×4 8×8×3½ |
8.62 8.62 8.62 8.62 8.62 |
8.62 6.62 5.56 4.50 4.00 |
7.00 7.00 7.00 7.00 7.00 |
7.00 6.62 6.38 6.12 6.00 |
| 10×10×10 10×10×8 10×10×6 10×10×5 10×10×4 |
10.75 10.75 10.75 10.75 10.75 |
10.75 8.62 6.62 5.56 4.50 |
8.50 8.50 8.50 8.50 8.50 |
8.50 8.00 7.62 7.50 7.25 |
| 12×12×12 12×12×10 12×12×8 12×12×6 12×12×5 |
12.75 12.75 12.75 12.75 12.75 |
12.75 10.75 8.62 6.62 5.56 |
10.00 10.00 10.00 10.00 10.00 |
10.00 9.50 9.00 8.62 8.50 |
| 14×14×14 14×14×12 14×14×10 14×14×8 14×14×6 |
14.00 14.00 14.00 14.00 14.00 |
14.00 12.75 10.75 8.62 6.62 |
11.00 11.00 11.00 11.00 11.00 |
11.00 10.62 10.12 9.75 9.38 |
| 16×16×16 16×16×14 16×16×12 16×16×10 16×16×8 16×16×6 |
16.00 16.00 16.00 16.00 16.00 16.00 |
16.00 14.00 12.75 10.75 8.62 6.62 |
12.00 12.00 12.00 12.00 12.00 12.00 |
12.00 12.00 11.62 11.12 10.75 10.38 |
| 18×18×18 18×18×16 18×18×14 18×18×12 18×18×10 18×18×8 |
18.00 18.00 18.00 18.00 18.00 18.00 |
18.00 16.00 14.00 12.75 10.75 8.62 |
13.50 13.50 13.50 13.50 13.50 13.50 |
13.50 13.00 13.00 12.62 12.12 11.75 |
| 20×20×20 20×20×18 20×20×16 20×20×14 20×20×12 20×20×10 20×20×8 |
20.00 20.00 20.00 20.00 20.00 20.00 20.00 |
20.00 18.00 16.00 14.00 12.75 10.75 8.62 |
15.00 15.00 15.00 15.00 15.00 15.00 15.00 |
15.00 14.50 14.00 14.00 13.62 13.12 12.75 |
| 22×22×22 22×22×20 22×22×18 22×22×16 22×22×14 22×22×12 22×22×10 |
22.00 22.00 22.00 22.00 22.00 22.00 22.00 |
22.00 20.00 18.00 16.00 14.00 12.75 10.75 |
16.50 16.50 16.50 16.50 16.50 16.50 16.50 |
16.50 16.00 15.62 15.00 15.00 14.62 14.12 |
| 24×24×24 24×24×22 24×24×20 24×24×18 24×24×16 24×24×14 24×24×12 24×24×10 |
24.00 24.00 24.00 24.00 24.00 24.00 24.00 24.00 |
24.00 22.00 20.00 18.00 16.00 14.00 12.75 10.75 |
17.00 17.00 17.00 17.00 17.00 17.00 17.00 17.00 |
17.00 17.00 17.00 16.50 16.00 16.00 15.62 15.12 |
| 18×18×18 18×18×16 18×18×14 18×18×12 18×18×10 18×18×8 |
18.00 18.00 18.00 18.00 18.00 18.00 |
18.00 16.00 14.00 12.75 10.75 8.62 |
13.50 13.50 13.50 13.50 13.50 13.50 |
13.50 13.00 13.00 12.62 12.12 11.75 |
| 18×18×18 18×18×16 18×18×14 18×18×12 18×18×10 18×18×8 |
18.00 18.00 18.00 18.00 18.00 18.00 |
18.00 16.00 14.00 12.75 10.75 8.62 |
13.50 13.50 13.50 13.50 13.50 13.50 |
13.50 13.00 13.00 12.62 12.12 11.75 |
| Nominal Pipe Size | SGP | STD | S40 | X-S | S80 | XX-S | S160 |
|---|---|---|---|---|---|---|---|
| ½×½ | 0.09 | 0.09 | 0.09 | 0.11 | 0.11 | 0.17 | 0.12 |
| ¾×¾ ¾×½ |
0.13 0.12 |
0.13 0.12 |
0.13 0.12 |
0.17 0.16 |
0.17 0.16 |
0.26 0.24 |
0.21 0.19 |
| 1×1 1×¾ 1×½ |
0.24 0.23 0.22 |
0.25 0.24 0.23 |
0.25 0.24 0.23 |
0.32 0.30 0.29 |
0.32 0.30 0.29 |
0.53 0.49 0.47 |
0.41 0.38 0.37 |
| 1¼×1¼ 1¼×1 1¼×¾ 1¼×½ |
0.42 0.39 0.37 0.36 |
0.43 0.40 0.37 0.36 |
10.43 0.40 0.37 0.36 |
0.56 0.53 0.48 0.47 |
0.56 0.53 0.48 0.47 |
0.95 0.89 0.84 0.81 |
0.69 0.65 0.62 0.59 |
| 1½×1½ 1½×1¼ 1½×1 1½×¾ 1½×½ |
0.58 0.56 0.53 0.51 0.49 |
0.61 0.59 0.56 0.53 0.51 |
0.61 0.59 0.56 0.53 0.51 |
0.81 0.78 0.74 0.70 0.67 |
0.81 0.78 0.74 0.70 0.67 |
1.40 1.35 1.28 1.21 1.17 |
1.07 1.01 0.97 0.92 0.90 |
| 2×2 2×1½ 2×1¼ 2×1 2×¾ |
0.86 0.80 0.77 0.73 0.70 |
0.88 0.82 0.79 0.75 0.71 |
0.88 0.82 0.79 0.75 0.71 |
1.20 1.11 1.07 1.01 0.98 |
1.20 1.11 1.07 1.01 0.98 |
2.16 2.00 1.91 1.81 1.76 |
1.78 1.63 1.56 1.50 1.45 |
| 2½×2½ 2½×2 2½×1½ 2½×1¼ 2½×1 |
1.42 1.31 1.25 1.22 1.18 |
1.74 1.56 1.51 1.48 1.36 |
1.74 1.56 1.51 1.48 1.36 |
2.28 2.06 1.98 1.94 1.80 |
2.28 2.06 1.98 1.94 1.80 |
3.92 3.56 3.40 3.32 3.22 |
2.86 2.64 2.48 2.42 2.36 |
| 3×3 3×2½ 3×2 3×1½ 3×1¼ |
1.87 1.79 1.68 1.62 1.60 |
2.41 2.29 2.12 2.06 2.02 |
2.41 2.29 2.12 2.06 2.02 |
3.25 3.07 2.85 2.77 2.74 |
3.25 3.07 2.85 2.77 2.74 |
5.90 5.53 5.18 5.03 4.95 |
4.55 4.23 4.02 3.87 3.80 |
| 4×4 4×3 4×2½ 4×2 4×1½ |
3.13 2.92 2.84 2.72 2.66 |
4.12 3.83 3.71 3.53 3.48 |
4.12 3.83 3.71 3.53 3.48 |
5.77 5.33 5.15 4.94 4.83 |
5.77 5.33 5.15 4.94 4.83 |
10.60 9.76 9.39 9.02 8.87 |
8.50 7.92 7.56 7.34 7.23 |
| 5×5 5×4 5×3 5×2½ 5×2 |
4.53 4.30 4.08 4.00 3.90 |
6.54 6.13 5.83 5.71 5.58 |
6.54 6.13 5.83 5.71 5.58 |
9.20 8.63 8.19 8.01 7.92 |
9.20 8.63 8.19 8.01 7.92 |
17.30 16.10 15.30 15.00 14.70 |
14.80 13.70 13.00 12.80 12.50 |
| 6×6 6×5 6×4 6×3 6×2½ |
6.84 6.45 6.23 6.01 5.92 |
9.58 9.08 8.67 8.38 8.36 |
9.58 9.08 8.67 8.38 8.36 |
14.50 13.60 13.00 12.60 12.50 |
14.50 13.60 13.00 12.60 12.50 |
27.20 25.60 24.50 23.70 23.30 |
23.30 21.90 20.80 20.10 19.80 |
| 8×8 8×6 8×5 8×4 |
12.80 11.90 11.50 11.30 |
17.90 16.60 16.10 15.70 |
17.90 16.60 16.10 15.70 |
27.10 25.20 24.30 23.70 |
27.10 25.20 24.30 23.70 |
45.70 43.00 41.40 41.00 |
47.20 43.50 42.10 40.30 |
| 10×10 10×8 10×6 10×5 10×4 |
21.80 20.40 19.50 19.20 18.90 |
30.40 28.50 27.20 26.80 26.80 |
30.40 28.50 27.20 26.80 26.80 |
41.00 38.90 37.00 36.20 36.20 |
49.00 45.80 43.90 43.10 42.50 |
79.20 54.40 71.50 70.00 68.90 |
88.00 81.40 78.50 77.00 76.30 |
| 12×12 12×10 12×8 12×6 12×5 |
32.00 30.40 29.00 28.10 27.80 |
43.60 41.60 39.70 38.40 38.70 |
48.70 45.30 42.50 42.00 41.70 |
57.70 55.20 53.10 51.20 51.20 |
79.20 74.80 71.40 69.50 68.70 |
113.00 107.00 102.00 100.00 98.30 |
143.00 135.00 128.00 125.00 124.00 |
| 14×14 14×12 14×10 14×8 14×6 |
44.70 42.70 41.20 40.00 39.00 |
53.50 51.90 49.90 48.20 47.10 |
62.40 60.20 57.60 55.80 54.50 |
70.90 68.80 66.30 64.50 62.60 |
104.00 100.00 95.90 92.90 91.00 |
– – – – – |
186.00 179.00 174.00 168.00 164.00 |
| 16×16 16×14 16×12 16×10 16×8 16×6 |
55.20 54.20 52.70 51.20 49.40 48.50 |
66.10 64.90 63.10 61.30 59.80 58.50 |
88.00 86.00 84.00 82.00 79.00 77.00 |
87.70 86.10 83.60 81.20 80.00 77.80 |
145.00 140.00 136.00 132.00 129.00 127.00 |
– – – – – – |
260.00 255.00 248.00 241.00 235.00 230.00 |
| 18×18 18×16 18×14 18×12 18×10 |
70.00 67.90 66.90 65.40 63.40 |
83.90 91.40 80.20 78.30 76.90 |
125.00 121.00 119.00 117.00 114.00 |
111.00 108.00 106.00 104.00 102.00 |
204.00 197.00 194.00 189.00 186.00 |
– – – – – |
356.00 352.00 344.00 337.00 329.00 |
| 20×20 20×18 20×16 20×14 20×12 20×10 20×8 |
86.60 84.20 82.10 81.10 79.20 77.60 76.30 |
104.00 101.00 98.40 97.20 96.00 94.00 92.10 |
163.00 158.00 154.00 152.00 150.00 147.00 145.00 |
138.00 134.00 131.00 129.00 127.00 125.00 123.00 |
277.00 268.00 262.00 258.00 254.00 250.00 245.00 |
– – – – – – – |
502.00 488.00 475.00 469.00 462.00 452.00 444.00 |
| 22×22 22×20 22×18 22×16 |
106.00 103.00 101.00 98.90 |
126.00 123.00 120.00 117.00 |
198.00 193.00 188.00 183.00 |
167.00 163.00 159.00 156.00 |
365.00 356.00 347.00 340.00 |
– – – – |
657.00 640.00 624.00 610.00 |
| 24×24 24×22 24×20 24×18 |
116.00 115.00 114.00 111.00 |
139.00 138.00 136.00 133.00 |
252.00 249.00 247.00 241.00 |
185.00 183.00 181.00 177.00 |
438.00 432.00 427.00 418.00 |
– – – – |
800.00 790.00 782.00 764.00 |
| 26×26 26×24 26×22 26×20 |
147.00 144.00 141.00 138.00 |
176.00 172.00 169.00 166.00 |
319.00 312.00 308.00 302.00 |
234.00 229.00 225.00 221.00 |
– – – – |
– – – – |
– – – – |
| 28×28 28×26 28×24 28×22 |
165.00 163.00 160.00 157.00 |
198.00 197.00 193.00 190.00 |
359.00 356.00 350.00 347.00 |
264.00 261.00 256.00 252.00 |
– – – – |
– – – – |
– – – – |
| 30×30 30×28 30×26 30×24 |
190.00 188.00 185.00 182.00 |
228.00 226.00 222.00 218.00 |
414.00 406.00 356.00 350.00 |
304.00 301.00 296.00 291.00 |
– – – – |
– – – – |
– – – – |
| 32×32 32×30 32×28 32×26 |
217.00 213.00 209.00 208.00 |
259.00 256.00 252.00 250.00 |
474.00 466.00 458.00 455.00 |
347.00 341.00 335.00 333.00 |
– – – – |
– – – – |
– – – – |
| 34×34 34×32 34×30 34×28 |
246.00 243.00 238.00 236.00 |
295.00 292.00 290.00 288.00 |
535.00 526.00 518.00 511.00 |
393.00 389.00 380.00 377.00 |
– – – – |
– – – – |
– – – – |
| 36×36 36×34 36×32 36×30 |
276.00 271.00 269.00 264.00 |
331.00 329.00 326.00 323.00 |
656.00 645.00 636.00 627.00 |
441.00 434.00 431.00 422.00 |
– – – – |
– – – – |
– – – – |
| 38×38 38×36 38×34 38×32 |
308.00 306.00 302.00 298.00 |
370.00 367.00 362.00 357.00 |
– – – – |
493.00 489.00 481.00 476.00 |
– – – – |
– – – – |
– – – – |
| 40×40 40×38 40×36 40×34 |
342.00 340.00 335.00 331.00 |
411.00 408.00 402.00 397.00 |
– – – – |
547.00 543.00 536.00 529.00 |
– – – – |
– – – – |
– – – – |
| 42×42 42×40 42×38 42×36 |
352.00 350.00 348.00 346.00 |
422.00 420.00 418.00 416.00 |
– – – – |
562.00 559.00 557.00 554.00 |
– – – – |
– – – – |
– – – – |
| 44×44 44×42 44×40 44×38 |
396.00 394.00 389.00 385.00 |
475.00 473.00 467.00 462.00 |
– – – – |
633.00 630.00 623.00 616.00 |
– – – – |
– – – – |
– – – – |
| 46×46 46×44 46×42 46×40 |
434.00 432.00 427.00 423.00 |
521.00 519.00 513.00 507.00 |
– – – – |
695.00 691.00 683.00 676.00 |
– – – – |
– – – – |
– – – – |
| 48×48 48×46 48×44 48×42 |
474.00 472.00 470.00 462.00 |
569.00 566.00 564.00 555.00 |
– – – – |
759.00 755.00 751.00 739.00 |
– – – – |
– – – – |
– – – – |
